6 mm Metal Planetary Gearbox
Modèle:ZWBMD006006
- puissance transmissible maximale
- 0.2W
- couple continu maximum
- 0.025Nm
Feuille de date pdf
Gearbox Specifications:
| Bearing | Porous bearing | Rolling bearing |
|---|---|---|
| Axial Endplay | ≤0.3mm | ≤0.3mm |
| Radial Loading on Output Shaft | ≤0.5N | ≤5N |
| Operating Temperature | -20℃ ~ +85℃ | |
Parameters：
| Gearbox Stages | 1 | 2 | 3 | 4 |
|---|---|---|---|---|
| Reduction Ratio | 5/6 | 23/31/41 | 110/148/198/266 | 531/711/952/12751708 |
| Max Rated Torque (gf.cm max) | 330 | 330 | 330 | 330 |
| Max Instant Torque (gf.cm max) | 800 | 800 | 800 | 800 |
| Gearbox Efficiency (%) | 87 | 74 | 63 | 56 |
| Length (mm) | 9.7 | 12.1 | 14.5 | 16.9 |
| Gear backlash | ≤3° | |||
Drawing:
Motor Specifications:
| Motors (Optional) | Coreless motor, Stepper motor |
|---|---|
| Voltage (Optional) | 3-12V |
| Input Speed | ≤30,000rpm |
| Current | 100mA max |
Performance Data:
| Model | Rated Speed (rpm) |
Max Speed (rpm) |
Max Rated Torque (gf.cm) | Max Instant Torque (gf.cm) |
Gear Ratio | Length (mm) |
Overall Length(L1) (mm) |
|---|---|---|---|---|---|---|---|
| ZWBMD006006-5 | 1563 | 6250 | 330 | 800 | 4.8 | 9.7 | 23.7 |
| ZWBMD006006-6 | 1166 | 4666 | 330 | 800 | 6.43 | ||
| ZWBMD006006-23 | 326 | 1302 | 330 | 800 | 23.04 | 12.1 | 26.1 |
| ZWBMD006006-31 | 243 | 972 | 330 | 800 | 30.86 | ||
| ZWBMD006006-41 | 181 | 726 | 330 | 800 | 41.33 | ||
| ZWBMD006006-110 | 68 | 271 | 330 | 800 | 110.6 | 14.5 | 28.5 |
| ZWBMD006006-148 | 51 | 203 | 330 | 800 | 148.1 | ||
| ZWBMD006006-198 | 38 | 151 | 330 | 800 | 198.4 | ||
| ZWBMD006006-266 | 28 | 113 | 330 | 800 | 265.7 | ||
| ZWBMD006006-531 | 14 | 57 | 600 | 1500 | 530.8 | 16.9 | 30.9 |
| ZWBMD006006-711 | 11 | 42 | 600 | 1500 | 711.0 | ||
| ZWBMD006006-952 | 8 | 32 | 600 | 1500 | 952.2 | ||
| ZWBMD006006-1275 | 6 | 24 | 600 | 1500 | 1275.2 | ||
| ZWBMD006006-1708 | 4 | 18 | 600 | 1500 | 1707.9 |
* The above specifications are subject to change without prior notice. They are for reference only and can be customized as required.
